Description
A 12V 120W DIN Rail PSU:
This product features a power factor corrected Universal AC Input of 90 – 264VAC, 47 – 63Hz and an output of 12V 10A, typical efficiency is 85.5%.
The output features low ripple and noise (100mV p-p) and has in-built protection for overload, OVP, SCP and OTP, line regulation is ± 0.5% and load regulation ± 1%.
This power supply meets safety requirements to EN62368-1 and UL508 with CE, UKCA, UL and cUL approvals. It complies with EMC emission standards EN55032 and EN61000-3-2, -3. EMC immunity compliance is to EN61000-4-2,3,4,5,6,8,11, EN55035, EN61000-6-2 and EN50082-2. The operating temperature range of -20 to +70°C (derate linearly 2.5% per degree from 51 to 70 degrees).
This unit has a slim metal case with dimensions of 125 x 113 x 40mm and achieves full output power with convection cooling. Input and output connectors are via terminal blocks.
This 12V 120W DIN Rail PSU is designed to cover a wide range of modern applications. These include, but are not limited too scientific, industrial and automation equipment.
