C150-1
Features
- 150W Travel PD Charger
- Multi-output
- PD 3.0/3.1
- 2 x USB-C and 2 x USB-A Outputs
- High Efficiency
- 12V – 24V Input
- 2M Input Lead
- Compact Package
150W Travel, Multi-output, PD 3.0/3.1 Charger:
This 150W Travel, multi-output, PD 3.0/3.1 charger provides four outputs. There are two USB-C and two USB-A connectors. The first USB-C output, C1, provides a maximum of 100W (5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A and 28V/5A). The second USB-C output, C2, provides a maximum of 20W (5V/3A, 9V/2.22A and 12V/1.67A). The two USB-A outputs, A1 & A2, provide a maximum of 18W each (5V/3A, 9V/2A and 12V/1.5A). The input is provided via a standard cigarette lighter plug, with a 2M lead, and covers a range of 12V – 24V DC.
These products meet the latest approvals with CE, UKCA and PSE safety and EN50498, FCC 47 and UL2089 EMC requirements. Designed for modern, slim, electronic products these chargers have a compact housing with nominal dimensions of 91.6 x 58.3 x 25.6mm. These chargers meet modern efficiency legislation.
This charger is designed for use in a travel environment with consumer electronic products. It can be used for intelligent identification and charging of mobile phones, tablets, laptops and other digital electronic products.
