Description
A 24VDC 2W Unregulated SIP7 DC/DC Converter:
This 24VDC 2W Unregulated SIP7 DIP DC/DC Converter is rated for an output current of 83mA max with efficiency up to 89%. The input voltage is nominally 12V ±10%, in-built continuous short circuit protection is provided as standard. Load regulation is 6% and line regulation is ±1.5% max. Output ripple and noise is typically 60mV P-P (20MHz bandwidth).
These parts feature an industry standard SIP7 package with 1.5KV DC input to output isolation. The case is manufactured from UL94-V0 black plastic and weighs 2.0g. Dimensions are 19.65 x 7.05 x 10.16mm. The operating temperature range is -40 to +105°C and cooling is by Free air convection.
These converters are widely used in distributed power systems and meet UL/EN/IEC62368-1. Applications may include battery systems, renewable energy, data acquisition, telecom, industrial control systems, wireless networks and IoT devices.
